Features
Features
- Wide Dynamic Range up to 76 dB
- High Accuracy of ± 3%
- Exceptional 0.001 dB Resolution
- Low-brightness, eye-comfort display for extended use
- Space-saving design for vertical or horizontal placement
- Supports remote control via Ethernet port
- USB Type-C charging
Application
- Research, production and testing of optical devices
Description
Ascentac TestMate2400 Series, Multi-channel Optical Power Meter, delivers high accuracy across a wide dynamic range. Fully compatible with both SM and MM fibers, it is ideal for the simultaneous testing of multi-channel optical components.
Its compact, dual-orientation design maximizes valuable bench space. The intuitive interface and clear display streamline the entire testing workflow, ensuring a user-friendly and efficient experience.
For data management, test results can be stored directly to a USB drive. The standard Ethernet (LAN) and RS232 ports provide robust options for remote control and automated testing, with seamless data transfer to a PC to boost overall productivity.
